Diesel Engine 2 Stroke – Physics Equipment

Diesel Engine Model is a model of two stroke water cooled diesel engine made in ast alloy metal. Ignition simulated by means of a miniature bulb. Fuel supply is also sectioned. With hand crank proved for manual operation depicting cam operated inlet and exhaust valves.

• Model that represents the internal structure of a diesel engine.
• Internal surfaces are finished in different colors to indicate air, fuel, gas mixture, and exhaust gas content.
• Includes can operated jerk pump and manually operated air inlet diaphragm injection nozzle and starting valve.
• Crankshaft can be rotated by hand wheel to show the operating cycle.
• Firing point of the engine is shown with a lamp which glows at the correct point in the cycle.
• Cast alloy construction on polished wooden base.
